"Fluorescent efficiency of three m-carborane-anthracene derivatives" featured in UAB Divulga

The article "Efficient blue light emitting materials based on m-carborane-anthracene dyads. Structure, photophysics and bioimaging studies" published in 2019 in Biomaterials Science, by Núñez et al. has been featured recently in UAB Divulga. You can find the text in English, Catalan and Spanish.

Anna May
29 April 2020

Fluorescent efficiency of three m-carborane-anthracene derivatives

Researchers of the Institut de Ciència de Materials de Barcelona (ICMAB-CSIC), with the Departament de Biologia Cel·lular, Fisiologia i Immunologia de la UAB have developed materials that emit efficient blue light, combining the properties of anthracene and m-carborane, and have analized their toxicity and acumulation inside the cell. These types of compounds are used to design optical devices and as probes in bioimaging studies. Moreover, in the case of new synthesized materials, the presence of boron may be useful in cancer therapy.

Anthracene derivatives are molecules with excellent luminescence properties, which make them perfect scaffolds for optical applications. Furthermore, carborane clusters, C2B10H12, are fascinating chemical species characterized by a unique 3D structure with σ-delocalization, high thermal and chemical stability, hydrophobicity and low toxicity in biological systems. The ortho- (1,2-C2B10H12) and meta-carborane (1,7-C2B10H12) isomers have different electronic properties, among them, their electron-withdrawing capacity.

Our group has demonstrated that in carborane-containing fluorophores, the emission properties in solution depend critically on the cluster isomer and the fluorescence efficiency can be tailored by changing the substituent at the second C atom of the cluster (Cc). Noticeably, the m-carborane is a perfect platform to boost the photoluminescent properties of organic π-conjugated systems linked to it in both, solution and solid states. In the last decade, the development of boron cluster-based organic π-conjugated systems have attracted huge interest as active materials in (opto)electronic devices, solar cells, biological sensors and imaging. Fluorescence imaging techniques have been used to visualize bio-components and bio-processes by transforming the chemical and biological information into detectable signals.

Owing to our interest in using luminescent carborane derivatives as fluorescence probes for biological systems, in this work we have developed efficient blue light emitting materials by combining the properties of the anthracene and m-carborane, and we have analysed their cytotoxicity and cellular uptake. For this purpose, we have synthesized three m-carborane-anthracene dyads, in which the carborane is non-iodinated, mono-iodinated or di-iodinated at the boron atoms, and the anthracene fragment is linked to one Cc through a CH2 spacer.

All the molecules exhibit exceptional fluorescence properties with very high quantum yields of around 100% in solution with emission maxima of around 415 nm, which corresponds to the emission of the anthracene group. These results indicate that by simply linking the m-carborane fragment to one anthracene unit produces a significant enhancement of the fluorescence in the final compounds. Notably, the three conjugates show good fluorescence efficiency in aggregate state with quantum yields in the range 19–23%. All these results indicate that our dyads are extremely good emitters in solution while maintaining the emission properties in the aggregate state.

None of the compounds shows cytotoxicity at different concentrations for HeLa cells. Confocal microscopy studies confirm that, although compounds exhibit a high fluorescence intensity emission, the one with two iodine groups is the best-internalized by cells. This suggests that the presence of iodine leads to a more efficient transport across the plasma membrane and a better cellular uptake of the compounds. It is also demonstrated that cell internalization is done by endocytosis, an energy-dependent (ATP consuming) process in which extracellular molecules are internalized.

In conclusion, this compound is an excellent candidate as a fluorescent dye for bioimaging studies in fixed cells. Furthermore, due to the high boron content and exceptional cellular uptake of our compounds, they could be used as potential anticancer agents for Boron Neutron Cancer Therapy (BNCT).

Rosario Nunez1 and Carme Nogués2
1Institut de Ciència de Materials de Barcelona (ICMAB-CSIC), Campus UAB.
2Departament de Biologia Cel·lular, Fisiologia i Immunologia (UAB)
Figure: Fuorescence intensity emitted by cells incubated for 4 h with 10 µM of diiodinated antracene-m-carborane. Image obtained with the confocal laser scanning microscope.
